| Capacity | Machine screw : M3 – M8 (1/8” – 5/16”) |
| Standard Bolt: M3 – M8 (1/8” – 5/16”) | |
| High Tensile Bolt: M3 – M6 (1/8” – 1/4”) | |
| Coarse thread (in length): 22 – 45mm (7/8” – 1-3/4”) | |
| Hex Shank | 6.35 mm (1/4”) |
| No Load Speed (RPM) | 0 – 2,450 |
| Impacts Per Minute (IPM) | 0 – 3,000 |
| Max Fastening Torque | 25 N·m (220 in.lbs.) |
| Dimensions Straight Type | 282x42x52mm |
| (L x W x H) | (11-1/8”x1-5/8”x2-1/16”) |
| Dimensions Pistol Type | 227x42x142mm |
| (L x W x H) | (8-15/16”x1-5/8”x5-5/8”) |
| Net Weight | 0.55 – 0.56 kg (1.2 lbs) |
